2.5 Connecting Temperature Sensor
52
Procedure
1. Move the shutter to reveal the temperature
sensor terminal.
2. Connect the temperature sensor to the
temperature sensor terminal.
Temperature measurement begins auto-
matically.
2.5 Connecting Temperature
Sensor
Temperature sensors may be damaged by
high voltage or static electricity. Do not
expose the temperature sensor to excessive
impact, or allow the cable to be bent, since
malfunction or faulty connection may result.
Temperature sensors cannot be used
simultaneously with test leads.
Move the shutter.
Temperature
sensor terminal
To Next Page
