Hioki 3455 - Measuring Insulation Resistance

1.5 Screen Setup
1
2
3
4
5
6
7
8
9
10
11
付録
索引
29
 3.2 "Measuring Insulation Resistance" (page 56)
 3.2.5 "Switching to Leakage Current Indication"
(page 68)
Measuring Insulation Resistance
Actual output
voltage
Blinking
> blinks if the
input exceeds
the measure-
ment range.
Elapsed time Insulation resistance
The screen is switched over with the
key.
Leakage Current Display
Blinking
Elapsed time
Actual output
voltage
The bar graph
shows the
resistance
measurement.
< blinks at
below 1 nA.
Current measurement
