2.1 Supplying Power
1
2
3
4
5
6
7
8
9
10
11
付録
索引
39
2.1.3 Connecting the AC Adapter
• Optional 9753 AC ADAPTER can be used.
• When the AC adapter is connected to the
tester, you can charge the battery pack,
communicate with a PC, perform temper-
ature measurement, and edit the settings.
However, you cannot measure insulation
resistance, leakage current or voltage.
• Turn the instrument off before connect-
ing the AC adapter to the instrument
and to AC power.
• Use only the specified Model 9753 AC
ADAPTER. AC adapter input voltage
range is 100 to 240 VAC (with ±10% sta-
bility) at 50/60 Hz. To avoid electrical
hazards and damage to the instrument,
do not apply voltage outside of this
range.
• To avoid electrical accidents and to
maintain the safety specifications of
this instrument, connect the power cord
provided only to a 3-contact (two-con-
ductor + ground) outlet.
The AC adapter cannot be used when
performing measurement using tester
leads.
