6.2 Changing and Checking Voltage Application Time for
Step Voltage Test
128
6. Press the key.
The time changes from blinking to con-
tinuously lit.
Setting of the time has been completed.
• The time can be set up on a PC using the
data analysis software for 3455.
• The data analysis software for 3455 must
be installed on the PC.
Details See 6.4 "Communicating with PC"
(page 134).
6.2.2 Checking Time Setting
Procedure
1. Press the key while in standby
state, and the voltage indication will
blink.
2. Choose a step voltage test mode
([STEP2.50 kVSET] or [STEP5.00
kVSET]) and press the key.
The time for one step appears.
The time can also be set up on a PC
To Next Page
