Replacement
Procedure
Tools: Phillips screwdriver
1. Turn off power and disconnect the test
leads, AC adapter, and USB cable from
the tester.
See 2.2 "Turning Power On and Off" (page 44).
2. Loosen the set screw on the rear of the
tester and remove the battery cover.
3.
Disconnect the plug of the battery pack
from the connector of the tester.
To Next Page
