3.4 Measuring Temperature
78
• If temperature measurement is stopped using the
key, measurement may be resumed by pressing
the key.
• When an insulation resistance measurement is held, if
the temperature sensor is disconnected, the tempera-
ture indication switches to the elapsed time indication at
the time of insulation resistance measurement. To dis-
play the held temperature instead of the elapsed time,
press the key. (The temperature will blink.)
• Held measurement values are cleared when power is
turned off. To save the data, use the memory function.
See 5.1.1 "Manual Recording (Recording result of one mea-
surement session)" (page 103).
• Settings cannot be edited during temperature measure-
ment. To edit settings, stop temperature measurement.
•[OF] means exceeding 70.0°C.
[-OF] means below -10.0°C.
After measuring temperature
(Disconnecting the temperature sensor,
resistance value is held)
To Next Page
