8.2 Displaying the Event List
122
Event times, list notation, and saved items
Event items
Event list
notation
IN/OUT/
SENSE
Saved items
Measurement items
Event
waveform
High-speed
waveform
Fluctuation
data
Transient overvoltage Tran IN/OUT
All instantaneous values
(Frequency, voltage, cur-
rent, power, power factor,
unbalance factor, harmonic
voltage, harmonic current,
harmonic power, harmonic
voltage distortion factor,
harmonic current distortion
factor, K factor, high-order
harmonic voltage compo-
nent and current compo-
nent, etc.)
Yes
Transient over-
voltage waveform
Swell Swell IN/OUT Yes Yes
Dip Dip IN/OUT Yes Yes
Interruption Intrpt IN/OUT Yes Yes
Inrush current
Inrush
(Irms1/2)
IN/OUT Yes Yes
Frequency Freq IN/OUT Yes
Frequency cycle Freq_wav IN/OUT Yes
Voltage waveform
peak
Upk IN/OUT Yes
RMS voltage Urms IN/OUT/SENSE Yes
Voltage DC change
(CH4 only)
Upp IN/OUT Yes
Current waveform
peak
Ipk IN/OUT Yes
RMS current Irms IN/OUT/SENSE Yes
Current DC change
(CH4 only)
Ipp IN/OUT Yes
Active power P IN/OUT Yes
Apparent power S IN/OUT Yes
Reactive power Q IN/OUT Yes
Power factor/
displacement factor
PF IN/OUT Yes
Voltage
negative-phase
unbalance factor
Uunb IN/OUT Yes
Voltage zero-phase
unbalance factor
Uunb0 IN/OUT Yes
Current
negative-phase
unbalance factor
Iunb IN/OUT Yes
Current zero-phase
unbalance factor
Iunb0 IN/OUT Yes
Harmonic voltage Uharm IN/OUT Yes
Harmonic current Iharm IN/OUT Yes
Harmonic power Pharm IN/OUT Yes
Phase difference of
harmonic voltage and
harmonic current
Pphase IN/OUT Yes
Total harmonic volt-
age distortion factor
Uthd IN/OUT Yes
Total harmonic current
distortion factor
Ithd IN/OUT Yes
K factor KF IN/OUT Yes
High-order harmonic
voltage component
UharmH IN/OUT Yes
High-order har-
monic waveform
High-order harmonic
current component
IharmH IN/OUT Yes
High-order har-
monic waveform
Voltage waveform
comparison
Wave Yes
Timer event Timer Yes
Continuous event Cont Yes
External event Ext Yes
Manual event Manu Yes
Start Start Yes
Stop Stop Yes
GPS
Note 1
GPS_IN Yes
GPS_OUT Yes
GPS_Err Yes
