Page #196 background imageLoading...
Page #196 background image
13.5 Operating Specifications
190
Operating modes Three modes: [SETTING], [RECORDING] (including [WAITING]), and [ANA-
LYZING]
A group of screens including [SYSTEM], [VIEW], [TIMEPLOT], and [EVENT]
displays groups exists for each mode.
Recording start
timing
Recording starts at a round TIMEPLOT interval time. For TIMEPLOT intervals of
150/180 cycles, recording starts in 1-minute increments.
Power outage
processing
In the event of a power outage during recording, the instrument resumes record-
ing once the power is back on (integral power starts from 0).
[SETTING]
(SETTING)
Instrument has been turned on, and there is no data stored internally.
[WAITING]
(WAITING)
Effective from the time the START/STOP button is pressed until the recording
start time
[RECORDING]
(RECORDING)
Recording has started, and measurement data is being saved on the SD mem-
ory card.
[ANALYZING]
(ANALYZING)
Recording has stopped, and the instrument's internal measurement data can be
analyzed.
13.5 Operating Specifications
[SYSTEM] Settings can be changed, and measured values are updated approxi-
mately once every 0.5 s.
[VIEW] Screen updated approximately once every 0.5 s
[TIME PLOT] None
[EVENT] None
START LED Off
[SYSTEM] Settings cannot be changed, and measured values are updated approx-
imately once every 0.5 s.
[VIEW] Screen updated approximately once every 0.5 s
[TIME PLOT] Standby display with time series graph
[EVENT] Standby display
START LED Flashing
[SYSTEM] Settings cannot be changed, and measured values are updated approx-
imately once every 0.5 s.
[VIEW] Screen updated approximately once every 0.5 s
[TIME PLOT] Screen updated every TIMEPLOT interval
[EVENT] Screen updated every time an event occurs
START LED On
[SYSTEM] Settings cannot be changed, and measured values are updated approx-
imately once every 0.5 s.
[VIEW] Analysis of event specified on the [TIMEPLOT] or [EVENT] screen
[TIME PLOT] Time series graph display
[EVENT] Event display
START LED Off
