5.5 Changing Event Settings
66
5.5 Changing Event Settings
What is an event?
See: "Appendix 2 Explanation of Power Supply Quality Parameters and Events"
List of event settings
Event parameter
Order
selection
Additional
functionality
Channel
selection
Threshold (Note 9) Note
Transient overvoltage
(1,2,3) (4)
(OFF)
0 to 6000 Vpk
Specify as absolute value.
1,4
Swell Slide
(1,2,3) (-)
(OFF)
0 to 200% 1,5
Dip Slide
(1,2,3) (-)
(OFF)
0 to 100% 1,5
Interruption
(1,2,3) (-)
(OFF)
0 to 100% 1,5
Inrush current
(1,2,3) (4)
(OFF)
0 to (varies with range) A 1,4,5
Frequency
(U1) (-)
(OFF)
0.1 to about 9.9 Hz 5
Frequency cycle
(U1) (-)
(OFF)
0.1 to about 9.9 Hz 5
Voltage
waveform peak
(1,2,3) (4)
(OFF)
0 to 1200 Vpk 1,4,7
RMS voltage
Phase/line
sense
(1,2,3) (4)
(OFF)
0 to 780 V
Specify upper and lower limits.
1,3,4,5
DC voltage change
(CH4 only)
(-,-,-) (4)
(OFF)
0 to 1200 V 1,5
Current
waveform peak
(1,2,3) (4)
(OFF)
0 to (varies with range) A×4 1,4,7
RMS current Sense
(1,2,3) (4)
(OFF)
0 to (varies with range) A 1,4,5
DC current change
(CH4 only)
(-,-,-) (4)
(OFF)
0 to (varies with range) A×4 1,5
Active power
(1,2,3)(sum)
(OFF)
0 to varies with range
Specify as absolute value.
1,4,5,8
Apparent power
(1,2,3)(sum)
(OFF)
0 to varies with range 1,4,5,8
Reactive power
(1,2,3)(sum)
(OFF)
0 to varies with range
Specify as absolute value.
1,4,5,8
Power factor/displace-
ment power factor
PF/DPF
(1,2,3)(sum)
(OFF)
0 to 1 3,4,5
Negative-phase volt-
age unbalance factor
(-,-,-)
(sum)(OFF)
0 to 100% 5
Zero-phase voltage
unbalance factor
(-,-,-)
(sum)(OFF)
0 to 100% 5
Negative-phase cur-
rent unbalance factor
(-,-,-)
(sum)(OFF)
0 to 100% 5
Zero-phase current
unbalance factor
(-,-,-)
(sum)(OFF)
0 to 100% 5
Harmonic voltage
Orders
0 to 50
Level (RMS)/
content
percentage
(1,2,3) (4)
(OFF)
0 to 780V/0 to 100%
Specify 0-order as an absolute value.
1,2,3,4,
5,6
Harmonic current
Orders
0 to 50
Level (RMS)/
content
percentage
(1,2,3) (4)
(OFF)
1.3 × (0 to [varies with range]) A /0 to 100%
Specify 0-order as an absolute value.
1,2,3,4,
5,6
Harmonic power
Orders
0 to 50
Level/content
percentage
(1,2,3)(sum)
(OFF)
1.3 × (0 to [varies with range]) W
Specify as absolute value. /0 to 100%
1,2,3,4,
5,6,8
