Hioki PW3198 User Manual

5.5 Changing Event Settings
67
Chapter 5 Changing Settings (as necessary)
5
Note 1: The threshold range is expanded by the VT ratio and CT ratio settings (for harmonics, level value
only).
Note 2: Settings can be made for individual orders as specified in the “Order selection” column.
Note 3: Phase voltage/line voltage, level/content percentage/voltage content percentage or current power
level, THD-F/THD-R, power factor/displacement power factor selections are made in the system set-
tings.
Note 4: Thresholds can be set for separately for individual channels as grouped together (other than “OFF”)
in the “Channel selection” column. (However, channels 1, 2, and 3 must share the same setting.)
Note 5: Hysteresis applies. However, the frequency is fixed at 0.1 Hz.
Note 6: During 400 Hz measurement, harmonic voltage, harmonic current, harmonic power, and harmonic
voltage-current phase difference can be measured up to the 10th order.
Note 7: DC values from an approx. 200 ms aggregation are compared with the threshold only when CH4 is
set to DC.
Note 8: The sum value threshold is 2 X for 1P3W, 3P3W2M, and 3P3W3M, and 3 X for all others.
Note 9: The setting precision for thresholds is ±1 dgt.
Harmonic voltage-cur-
rent phase difference
Orders
1 to 50
(1,2,3)(sum)
(OFF)
0 to 180×
Specify as absolute value.
2,4,5,6
Total harmonic voltage
distortion factor
-F/-R
(1,2,3) (4)
(OFF)
0 to 100% 3,4,5
Total harmonic current
distortion factor
-F/-R
(1,2,3) (4)
(OFF)
0 to 500% 3,4,5
K factor
(1,2,3) (4)
(OFF)
0 to 500 4,5
High-order harmonic
voltage component
RMS
(1,2,3) (4)
(OFF)
0 to 600 V 1,4
High-order harmonic
current component
RMS
(1,2,3) (4)
(OFF)
0 to (varies with ran A) 1,4
Voltage waveform
comparison
(1,2,3) (-)
(OFF)
0 to 100% 1
Time event
(-,-,-) (-)
(OFF)
OFF,1,5,10,30 min,1,2 hour.
Continuous event
(-,-,-) (-)
(OFF)
OFF, 1, 2, 3, 4, 5 times
External event
(External)
(OFF)
None
Manual event None
Start None
Stop None
List of event settings
Event parameter
Order
selection
Additional
functionality
Channel
selection
Threshold (Note 9) Note
