9.4 Saving, Display and Deleting Measurement Data
143
89
Chapter 9 Data Saving and File Operations
(SYSTEM-MEMORY screen)
9
In the [SYSTEM]-[MEMORY]-[LIST] screen, when the cursor is moved to the stored data folder to be dis-
played and the F1 [Load] key is pressed, [Analyze] will be activated and the event list, trend data, detailed
trend data in the specified folder will be displayed.
Event, trend data and detailed trend data can be checked.
Refer to "Chapter 8 Checking Events (EVENT screen)" (p.119) for the Event Confirmation Method.
Return to [Settings] with the DATARESET key.
[TIMEPLOT] screen maximum display times
Display Measurement Data (Load)
• lThe maximum displayed times of the trend data, detailed trend data, and har-
monic trend data in the
[TIME PLOT] screen of the HIOKI PW3198 is subject to
certain constraints. To confirm all measured trend data, use the 9624-50 PQA-
HiView Pro Software.
• lMeasurement data can only be loaded on the instrument which measures.
Data measured in different versions will not load even if the instrument is the
same.
• The F1 [Load] key will appear when the cursor is in the stored data folder.
(B*******).
TIME PLOT
Interval
Recording Items setting
ALL DATA
(Saves all data)
P&Harm
(Saves RMS values and harmonics)
Power
(Saves RMS values only)
1sec 7 min. 52 sec. 15 min. 44 sec. 2 hours 37 min. 20 sec.
3sec 23 min. 36 sec. 47 min. 12 sec. 7 hours 52 min.
15sec 1 hour 58 min. 3 hours 56 min. 1 day 15 hours 20 min.
30sec 3 hours 56 min. 7 hours 52 min. 3 days 6 hours 40 min.
1min 7 hours 58 min. 15 hours 44 min. 6 days 13 hours 20 min.
5min 1 day 15 hours 20 min. 3 days 6 hours 40 min. 32 days 18 hours 40 min.
10min 3 days 6 hours 40 min. 6 days 13 hours 20 min. 35 days
15min 4 days 22 hours 9 days 20 hours 35 days
30min 9 days 20 hours 19 days 16 hours 35 days
1hour 19 days 16 hours 35 days 35 days
2hours 35 days 35 days 35 days
150/180 wave
(Approx. 3 sec)
23 min. 36 sec. 47 min. 12 sec. 7 hours 52 min.
