13.2 General Specifications
167
10
13
Chapter 13 Specifications
Functions 1. HTTP server function (compatible software: Internet Explorer Ver.6 or later
Remote operation application function, measurement start and stop control functions, system
configuration function, event list function (capable of displaying event waveforms, event vectors,
and event harmonic bar graphs)
2. Downloading of data from the SD memory card using the 9624-50 PQA-HiView Pro
(3) LAN Interface
(4) USB-F Interface
Connector Series B receptacle × 1
Method USB 2.0 (full-speed, high-speed), mass storage class
Connection destination Computer (Windows2000/WindowsXP/WindowsVista(32bit)/Windows7 (32/64bit))
Functions 1. Recognition of the SD memory card as a removable disk when connected to a computer
The instrument cannot be connected during recording (including standby operation) or analysis.
2. Downloading of data from the SD memory card using the 9624-50 PQA-HiView Pro
The instrument cannot be connected during recording (including standby operation) or analysis.
(5) External control interface
Connector 4-pin screwless terminal block × 1
External event input: EVENT IN terminal
× 1
External event output and V10 alarm: EVENT OUT terminal
× 1, GND terminal × 2
External event input External event input at TTL low level (at falling edge of 1.0 V or less and when shorted) between
GND terminal and EVENT IN terminal
Min. pulse width: 30 ms; rated voltage: -0.5 V to +6.0 V
External event output
Rated voltage -0.5 V to +6.0 V
External event output item setting Operation Pulse width
Short pulse output TTL low output at event generation between [GND] termi-
nal and [EVENT OUT] terminal
Low level for 10
ms or more
Long pulse output TTL low output at event generation between [GND] termi-
nal and [EVNET OUT] terminal
No external event output at START event
Low level for ap-
prox. 2.5 s
V10 alarm TTL low output at V10 alarm between [GND] terminal
and [EVENT OUT] terminal
Low level while
alarm occurring;
reverts to high at
data reset
Accessories and Options Specifications
Accessories
• Instruction manual .........................................................................................................1
• Measurement guide .......................................................................................................1
• L1000 Voltage Cord.......................................................................................................1
(8 cords, approx. 3 m each: 1 each red, yellow, blue, and gray as well as 4 black;
8 alligator clips: 1 each red, yellow, blue, and gray as well as 4 black)
• Spiral Tube...................................................................................................................20
• Input Cable Labels.........................................................................................................1
(For identifying channel of voltage cords and clamp sensors)
• Z1002 AC Adapter .........................................................................................................1
• Strap ..............................................................................................................................1
• USB cable......................................................................................................................1
(CSK00027*K0080 Approx. 1 m in length)
• Z1003 Battery Pack .......................................................................................................1
(Ni-MH, 7.2 V/4500 mAh)
• Z4001 SD memory card 2GB.........................................................................................1
Current measurement options 9660 Clamp-On Sensor (100 Arms rating)
9661 Clamp-On Sensor (500 Arms rating)
9667 Flexible Clamp-On Sensor (5000 Arms/500 Arms rating)
9669 Clamp-On Sensor (1000 Arms rating)
9694 Clamp-On Sensor (5 Arms rating)
9695-02 Clamp-On Sensor (50 Arms rating)
9695-03 Clamp-On Sensor (100 Arms rating)
9290-10 Clamp-On Adapter
9219 Connection Cable (for Model 9695-02/9695-03)
9657-10 Clamp-On Leak Sensor (10 Arms rating)
9675 Clamp-On Leak Sensor (10 Arms rating)
CT9691 Clamp on AC/DC Sensor (100 A/10 A rating) + CT6590 Sensor Unit
CT9692 Clamp on AC/DC Sensor (200 A/20 A rating) + CT6590 Sensor Unit
CT9693 Clamp on AC/DC Sensor (2000 A/200 A rating) + CT6590 Sensor Unit
CT9667 Flexible Clamp on Sensor
