14.4 Disposing of the Instrument

222

6. Remove the 17 screws shown in the following

diagram and remove the upper chassis.

7. Insert the tweezers between the battery

holder and the battery and lift up the

battery to remove it.

CALIFORNIA, USA ONLY

This product contains a CR Coin Lithium

Battery which contains Perchlorate Material

- special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/

perchlorate

Lithium

battery

Upper

chassis
