Chapter 11 Specifications
151
11
(8) Scaling Function
(9) Faulty Measurement Detection
Operation Measured values are corrected with the linear function R
S
= A × R + B
R
S
: Value after scaling
A : Gain coefficient Setting range: 0.2000 × 10
-3
to 1.9999 × 10
3
R : Measured value after zero-adjustment and temperature correction
B : Offset Setting range: 0 to ±1 × 10
9
(maximum resolution: 1 n)
Setting ON/ OFF
Display format See below.
Unit / none/ user-selected 3 characters (Except SI prefix)
Default setting OFF, A: 1.0000 ×1, B: 0, Unit: 
Range
Gain coefficient
(0.2000 to
1.9999) ×10
-3
(0.2000 to
1.9999) ×10
-2
(0.2000 to
1.9999) ×10
-1
(0.2000 to
1.9999) ×1
(0.2000 to
1.9999) ×10
(0.2000 to
1.9999) ×10
2
(0.2000 to
1.9999) ×10
3
30 m 00.000  000.00  0.0000 m 00.000 m 000.00 m 0.0000 00.000
300 m 000.00  0.0000 m 00.000 m 000.00 m 0.0000 00.000 000.00
3  0.0000 m 00.000 m 000.00 m 0.0000 00.000 000.00 0.0000 k
30  00.000 m 000.00 m 0.0000 00.000 000.00 0.0000 k 00.000 k
300  000.00 m 0.0000 00.000 000.00 0.0000 k 00.000 k 000.00 k
3 k 0.0000 00.000 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M
30 k 00.000 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M
300 k 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M 000.00 M
3 M 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M 000.00 M 0.0000 G
 Over Range Detection Function
Operation Indicates under- or over-range values in the following conditions:
• Measured value is outside of the measurement range
• Measured value is outside of the A/D converter input range
• Calculation result exceeded the number of display digits
 Current fault detection function
Operation Detects faults in which the stipulated measurement current cannot be applied.
No cancelation function.
Current fault mode set-
ting
Current fault (ERR signal output) / over-range (HI signal output)
Default setting Current fault (ERR signal output)
