Appendix 16 Calibration
A32
Calibration Conditions
Calibration equipment
Please use the following for calibration equipment.
Resistance measurement function
If the FLUKE 5520A cannot be used, please use the following equipment.
Appendix 16 Calibration
• Ambient temperature and humidity
23±5°C, 80%RH or less
• Power supply
100 to 240 V±10%, 50/60 Hz, distortion rate of 5% or less
• External magnetic field
Environment close to the Earth’s magnetic field
• Initialize settings by resetting the instrument.
Equipment
Calibration
point
Manufacturer Standard model
Standard resistor
10 m
Alpha Electronics Equivalent to CSR-10N
Standard resistor
100 m
Alpha Electronics Equivalent to CSR-R10
Multi-product calibrator
3
FLUKE Equivalent to 5520A
Multi-product calibrator
30
FLUKE Equivalent to 5520A
Multi-product calibrator
300
FLUKE Equivalent to 5520A
Multi-product calibrator
3 k
FLUKE Equivalent to 5520A
Multi-product calibrator
30 k
FLUKE Equivalent to 5520A
Multi-product calibrator
300 k
FLUKE Equivalent to 5520A
Multi-product calibrator
3 M
FLUKE Equivalent to 5520A
Resistance measurement leads HIOKI L2104 4-Terminal Lead
Equipment
Calibration
point
Manufacturer Standard model
Standard resistor
1
Alpha Electronics Equivalent to CSR-1R0
Standard resistor
10
Alpha Electronics Equivalent to CSR-100
Standard resistor
100
Alpha Electronics Equivalent to CSR-101
Standard resistor
1 k
Alpha Electronics Equivalent to CSR-102
Standard resistor
10 k
Alpha Electronics Equivalent to CSR-103
Standard resistor
100 k
Alpha Electronics Equivalent to CSR-104
Standard resistor
1 M
Alpha Electronics Equivalent to CSR-105
Equipment Calibration point Manufacturer Standard model
Dial-type resistor
30 to 300 k Alpha Electronics
Equivalent to ADR-6105M
Dial-type resistor
3 M Alpha Electronics
Equivalent to ADR-6106M
