This chapter explains measured value judgments (the comparator function). The compara-
tor function provides the following capabilities:
• Displaying information on the instrument (COMP lamp Hi/IN/Lo)
• Sounding the beeper
(By default, the beeper is disabled.)
See: "Checking Judgments Using Sound (Judgment Sound Setting Function)"(p.68)
• Displaying data away from the instrument
The L2105 LED Comparator Attachment is an option.
See: "Checking Judgments with the L2105 LED Comparator Attachment (Option)"(p.70)
• Outputting judgment results to external equipment
See: "Chapter 8 External Control (EXT I/O)" (p. 89)
Moreover, the judgment timing can be delayed.
See: "Delaying the judge timing"(p.66)
Judgment
Function
Chapter 5
Measured value > Upper limit value
Upper limit value Measured value Lower limit value
Measured value < Lower limit value
