1.3 Measurement Process
19
1
1.3 Measurement Process
Install this instrument (p. 5)
1
Rear Panel
Turn on the instru-
ment and cancel
the standby state
(p.28)
6
When finished measuring, turn the
power off (p.28).
Connect the temperature sensor
(p.27)
(When using the temperature correc-
tion function)
4
2
3
Make instrument settings
*1
Connect measurement leads (p.26)
7
Connect to the test sample (p.34)
8
Connect the power
cord (p.25)
Connect the external interface
(RM3544-01; as necessary)
5
• Using the printer (p.137)
• Using the USB or RS-232C inter-
face (p.121)
• Using the EXT I/O (p.89)
When clipping a small-gauge
wire
(Clip with the tip of the alligator
clips.)
When clipping a large-gauge
wire
(Clip with the back of the alligator
clips, where there are no teeth.)
6
3
4
2
5
Front Panel
Rear Front
