Chapter 11 Specifications
157
11
(5) L2105 LED Comparator Attachment output
TRIG/ PRINT filter function
Setting ON/ OFF
Response time 50 to 500 ms
Default setting OFF, 50 ms
Start Logic Setting
Setting OFF edge/ ON edge
Default setting ON edge
EOM output timing setting
Setting HOLD/ PULSE
Pulse width 1 ms to 100 ms
Default setting HOLD, 5 ms
EXT I/O test function
Operation Displays the EXT I/O input signal state and generates output signals as de-
sired.
External power output
Output voltage Sink output: 5 V ±10%, source output: -5 V ±10%, 100 mA max.
Isolation Floating from protective ground potential and measurement circuit
Insulation rating Terminal to ground voltage:
Not more than 50 VDC, 33 Vrms AC, and 46.7 Vpk AC
Output Comparator judgment output (HiLo or IN)
Output jack 3-pole earphone jack (φ2.5 mm)
Output voltage 5 V±0.2 V DC, 20 mA
