Hitachi DSP-110A6N User Manual

24
3. OPERATING PROCEDURE [How to Use the Liquid Crystal Display (LCD)]
3.3.6. Other Settings
Adjust the LCD brightness as follows:
To brighten:
Hold down the SET button and press the
MONITOR button.
To darken:
Hold down the SET button and press the
FUNCTION button.
The calendar and clock are set by Hitachi prior to
delivery. To reset the calendar and clock, contact
the local Hitachi distributor.
The following is a table of contents that can be set by
the LCD monitor and digital monitor (next section).
󱦯 Initial Setting
The language of the display can be switched to
Japanese, English or Chinese by the dip switch on
the back of the LCD monitor board. If the language
needs to be changed, consult with the local Hitachi
distributor.
󱦵 3-Language Display Switch
󱦱 Brightness Adjusting
󱦳 Digital Monitor Operation Classification
Bit 1 2 3 4 - 8
Japanese OFF OFF OFF
Not
used
English ON OFF OFF
Chinese OFF ON OFF
Setting for United
States
ON OFF ON
Test mode ON ON OFF
Power must be turned off before setting.
Function Item
LCD monitor
operation
Digital monitor
(F mode)
Remarks
MULTI-U SETTING
display
MODE -
○ F000
Dual, backup, etc
DUAL TIME
○
-
METHOD
○
SWITCHOVER
○
BACKUP
○
Differential pressure
UNLOAD
○
Differential pressure
ALT.TIME
△
(automatic change)
CONTROL MODE
-
○ (Factory set)
V type only
CONTROL SETTING
display
TYPE (left)
○ F019
Example: I type (load/unload type)
TYPE (center)
○ F018
Example: Setting 1
TYPE (right)
○
-
Option (not supported)
P-LOSS
○
Option (not supported)
PI-CA
○
Option (not supported)
P1
-
○ F022 -
Setting 1, Setting 2
P2
○ F022 -
Setting 1, Setting 2
TARGET - Prohibited to change
TIME LIMIT
○ (Factory set)
Energy saving mode decision time
TIME
○
-
SCHEDULE SETTING
display
MODE
○
Function switching
START/STOP
○
RECORD 1, 2
○
Operation data measurement
Other settings
Air compressor No.
-
○ F001
IPI
○ F002 -
Remote operation
○ F005 -
Dryer operation
○ F008 -
AUTO operation
○ F011 -
ECOMODE
○
Display switch button operation
Reset
Shutdown/Alarm
○
Reset button operation
Load count
○
Remote + display switch button
Maintenance
○
- Set button 7 sec. ON
Shutdwon/Alarm history -
○ F041
