96
11. PARTS LIST
415
426
425
462
302
401
453
454
455
427
F72
306
461
391
393
419
394
340
H56
H55
428
460
J26
F73
3
Motor Assembly
Ref.
No.
Description
302 Pull Gear
306 Pinion Gear, oil pump
340 Key
391 Shaft Seal
393 Gasket, shaft seal
401 Motor
415 O-Ring (motor flange)
419 Cover, shaft seal
425
Vibration Isolation Rubber
426 Support Bolt, gear case
427 Stad Bolt, motor support
428 Spacer
453 Bearing (Load-side)
454 Bearing (Anti-Load-side)
455 Grease
461 Gear Shaft, oil pump
462 M8 Flat Head Bolt
F72 Grease Pan (1)
F73 Grease Pan (2)
H55 Bolt with assistant
H56 Spacer, base
J26 Thermostat
To Next Page
