Hitron CGNV4 User Manual

Version 1.1, 02/2014. Copyright 2012 Hitron Technologies
19
Version 1.1, 02/2014. Copyright 2014 Hitron Technologies
19
Hitron CGNV4 User’s Guide
Figure 4: LEDs
Table 3: LEDs
LED STATUS DESCRIPTION
US Green, blinking The CGNV4 is searching for an upstream frequency
on the CABLE connection.
Green, steady The CGNV4 has successfully located and locked
onto an upstream frequency on the CABLE
connection.
Blue The CGNV4 is engaged in channel bonding on the
upstream connection.
Off There is no upstream activity on the CABLE
connection.

Hitron CGNV4 Specifications

General

Wi-Fi Standard	802.11n
Frequency Bands	2.4 GHz, 5 GHz
Ethernet Ports	4
USB Ports	1
DOCSIS Version	3.0
Downstream Channels	24
Upstream Channels	8
Type	Cable Modem Router
Max Download Speed	960 Mbps
Max Upload Speed	240 Mbps
Security Features	WPA, WPA2
Wi-Fi Frequency	2.4 GHz
