Hitron CGNV4 User’s Guide
DS Green, blinking The CGNV4 is searching for a downstream
frequency on the CABLE connection.
Green, steady The CGNV4 has successfully located and locked
onto a downstream frequency on the CABLE
connection.
Blue The CGNV4 is engaged in channel bonding on the
downstream connection.
Off There is no downstream activity on the CABLE
connection.
Status Blinking The CGNV4’s cable modem is registering with the
service provider’s CMTS.
On The CGNV4’s cable modem has successfully
registered with the service provider and is ready for
data transfer.
LAN Off No device is connected to one of the LAN ports.
Green, blinking A device is connected to one of the LAN ports via a
Fast Ethernet (100Mbps) link, and is transmitting or
receiving data.
Green, steady A device is connected to one of the LAN ports via a
Fast Ethernet (100Mbps) link, but is not transmitting
or receiving data.
Blue, blinking A device is connected to one of the LAN ports via a
Gigabit Ethernet (1000Mbps) link, and is
transmitting or receiving data.
Blue, steady A device is connected to one of the LAN ports via a
Gigabit Ethernet (1000Mbps) link, but is not
transmitting or receiving data.
WIRELESS
(2.4GHZ)
Off The 2.4GHz wireless network is not enabled.
Green, steady The 2.4GHz wireless network is enabled, and no
data is being transmitted or received over the
2.4GHz wireless network.
Green, blinking The 2.4GHz wireless network is enabled, and data
is being transmitted or received over the 2.4GHz
wireless network.
Bi-color Wi-Fi Protected Setup (WPS) is in operation on the
2.4GHz wireless network.
Table 3: LEDs
