Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
RF-PIR-DT - Continued
2 Devices Menu
2 Wired Devices Menu
1 RF Devices Menu
1 Add & ID RF Devices
2 Locate RF Devices
3 Remove RF Devices
4 RF Devs Options
1 Service Menu
3 Zone Menu
• The RF-PIR-DT’s programmable options can be accessed as follows;
• To get to either the RF-Zones or RF-Points options menu; select the Devices Menu. Then RF Devs Menu.
Next select the RF Devs Options.
• From there go to either the RF Zone Opts or RF Point Opts menu and then select the RF-PIR-DT number
in question.
• You can now select the sensitivity of the RF-PIR-DT. The three levels are LOW, MED and HI.
• Another option is Mon Sup (Monitored Supervisory signal) is defaulted to YES. When the device is “lost” for
>120 minutes, a supervisory alarm is flagged by the panel. This can be turned off by selecting NO. However,
we recommend that this feature is left as YES
2 Mon Sup YES
1 Settings MED
1 Add & ID RF Devices
1 RF Zone Opts
2 RF Point Opts
2 Locate RF Devices
3 Remove RF Devices
4 RF Devs Options
Note: The Radar sensitivity is only adjustable by twisting the on-board potentiometer.
!
The unit only flags an activation when the system is armed and
when both PIR and Radar circuits are simultaneously triggered.
2 Wired Devices Menu
1 RF Devices Menu
PIR located -LED turns on/off every second
• In the Locate: RF Zones or Locate: RF Points you will observe the following;
Note: To locate an RF-PIR-DT go to the Devices Menu in engineer mode and follow menu path below...
• You will automatically be brought to either zone 1 or the first point (P50)
• When you want to move on to the next zone or point then press
1 Locate:RF Zones
2 Locate:RF Points
1 Add & ID RF Devices
2 Locate RF Devices
3 Remove RF Devices
#
next
2 Wired Devices Menu
1 RF Devices Menu
• To remove an RF-PIR-DT go to the Devices Menu in engineer mode and follow menu path below.
• You will automatically be brought to either zone 1 or the first point (P50)
• Go to the zone or point you want to remove and press
1 Remove:RF Zones
2 Remove:RF Points
1 Add & ID RF Devices
2 Locate RF Devices
3 Remove RF Devices
REC
YES
20
