HKC Quantum70 Installation Manual

Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
RF-PIR-DT - Continued
Note: mount the unit 2.4m from the ground
2m
2m
2.4m 2.4m
2m
4m
6m 8m
10m
14m
2m
4m
8m
2m
4m
6m
8m
Vertical PIR Coverage
Vertical PIR Coverage
Horizontal PIR Coverage
Horizontal Radar Coverage (max.)
12m
1m
1m
2m
4m 6m 8m
10m 12m 14m
10m
2m
2m
4m
(close-in detection)
(close-in detection)
Horizontal PIR
Coverage
Fully
clockwise =
15m Radar
Detection
Fully anti-
clockwise =
7m Radar
Detection
6m
User warning: Do not partially or completely obscure the detector’s field of view.
!
Range of Detection
Specifications
Current Consumption
Battery Life
Radio Range
Frequency
Temperature
Mounting Height
Weight
EN 50131-2-4
Dimensions
Lithium 3Vdc (nom.) 1,400mAh
Standby: 8µA
Transmit: 55mA (peak)
Typically up to 3 years
868Mhz
2.4m
-10°C to +40°C
W=64mm H= 136mm D = 53mm
175g (including batteries)
Grade 2 Class II
Line-of-sight > 400m
Battery
21
