RF-SABB - Continued
Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
Specifications
Current Consumption
Siren
Range
Battery Life
Temperature
Dimensions
Weight
EN 50131-4
6x CR123A 3V Lithium batteries
13.7Vdc nom. (9Vdc min - 15Vdc max)
Quiescent (not in alarm): 27µA
Transmit: 40mA
Strobe (in alarm): 60mA (peak)
Siren (in alarm): 80mA (peak)
Total in alarm: 180mA (peak)
Typically >3 years
Line-of-sight > 400m
109dB at 1m (frequency sweep acoustic output)
-25°C to +60°C
1,225g
W=368mm H= 228mm D = 58mm
Grade 2 Class IV
Battery Supply
or...
Permanent Wired Supply
29
Note: If (shorthand for Status LEDs) are enabled the batteries will need to be replaced every 6
to 8 months. We recommend that if you would like to use this feature that a secondary battery pack is installed
(part number: BAT-PKRFSB6V). Alternatively wire 12Vdc to the SABB and remove the battery pack and
install a 6V NiMH rechargeable battery pack (part number: BAT-8.4)
StatLeds
!
