108
Pn No.
Size
Name
Setting range
Setting Unit
Factory
setting
Available
time
Categ
ory
Remar
ks
Pn860
M3
2
SVCMD_IO (input signal
monitoring)
Distribution function 1
0000～1717
-
0000
Effective
immediately
Setup
n.

X
Allocation of input signal monitoring for CN1-IN0 (SVCMD_IO)
0
Set CN1-13 input signal monitoring to bit 24 (IO_STS1).
1
Set CN1-13 input signal monitoring to bit 25 (IO_STS2).
2
Set CN1-13 input signal monitoring to bit 26 (IO_STS3).
3
Set CN1-13 input signal monitoring to bit 27 (IO_STS4).
4
Set CN1-13 input signal monitoring to bit 28 (IO_STS5).
5
Set CN1-13 input signal monitoring to bit 29 (IO_STS6).
6
Set CN1-13 input signal monitoring to bit 30 (IO_STS7).
7
Set CN1-13 input signal monitoring to bit 31 (IO_STS8).
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN0
0
Make CN1-IN0 input terminal bit allocation invalid.
1
Make CN1-IN0 input terminal bit allocation valid.
n.X
Allocation of input signal monitoring for CN1-IN1 (SVCMD_IO)
0～7
The allocation is the same as CN1-IN0.
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN1
0
Make CN1-IN1 input terminal bit allocation invalid.
1
Make CN1-IN1 input terminal bit allocation valid.
Pn861
M3
2
SVCMD_IO (input signal
monitoring)
Distribution function 2
0000～1717
-
0000
Effective
immediately
Setup
n.X
Allocation of input signal monitoring for CN1-IN2 (SVCMD_IO)
0～7
The allocation is the same as CN1-IN0.
n.

X

Valid/Invalid Selection of Input Signal Monitoring for CN1-IN2
0
Make CN1-IN2 input terminal bit allocation invalid.
1
Make CN1-IN2 input terminal bit allocation valid.
n.X
Allocation of input signal monitoring for CN1-IN3 (SVCMD_IO)
0～7
The allocation is the same as CN1-IN0.
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN3
0
Make CN1-IN3 input terminal bit allocation invalid.
1
Make CN1-IN3 input terminal bit allocation valid.
Pn862
M3
2
SVCMD_IO (input signal
monitoring)
Distribution function 3
0000～1717
-
0000
Effective
immediately
Setup
n.

X
Allocation of input signal monitoring for CN1-IN4 (SVCMD_IO)
0～7
The allocation is the same as CN1-IN0.
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN4
0
Make CN1-IN4 input terminal bit allocation invalid.
1
Make CN1-IN4 input terminal bit allocation valid.
n.

X

Allocation of input signal monitoring for CN1-IN5 (SVCMD_IO)
0～7
The allocation is the same as CN1-13.
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN5
0
Make CN1-IN5 input terminal bit allocation invalid.
1
Make CN1-IN5 input terminal bit allocation valid.
Pn863
M3
2
SVCMD_IO (input signal
monitoring)
Distribution function 4
0000～1717
-
0000
Effective
immediately
Setup
n.X
Allocation of input signal monitoring for CN1-IN6 (SVCMD_IO)
0～7
The allocation is the same as CN1-IN0.
n.X
Valid/Invalid Selection of Input Signal Monitoring for CN1-IN6
0
Make CN1-IN6 input terminal bit allocation invalid.
1
Make CN1-IN6 input terminal bit allocation valid.
n.X X
Appointment parameters (do not change it)
