HNC Electric HSD7-E Series - Page 93

87
Pn No.
Size
Name
Setting range
Setting
Unit
Factory
setting
Available
time
Categor
y
Rema
rks
Pn00A
2
Function selection
application switch A
0000～0044
-
0001
Power
restart
Setup
-
n.X
Stop Method in Case of Gr.2 Alarm
Remarks
0
DB stop or free running stop (stop method is the same as Pn001 =
n.X).
1
The set torque of Pn406 is used as the maximum torque to
decelerate and stop the motor.
The state after stopping depends on the setting of Pn001 =
n.X.
2
The set torque of Pn406 is used as the maximum torque to
decelerate and stop the motor.
And then enter a free running state.
3
According to the deceleration time of Pn30A, the motor is
decelerated and stopped.
The state after stopping depends on the setting of Pn001 =
n.X.
4
According to the deceleration time of Pn30A, the motor will
decelerate and stop, and then enter the free running state.
n.X
Stop method when forced to stop
Remarks
0
DB stop or free running stop (stop method is the same as Pn001 =
n.X).
1
The set torque of Pn406 is used as the maximum torque to
decelerate and stop the motor.
The state after stopping depends on the setting of Pn001 =
n.X.
2
The set torque of Pn406 is used as the maximum torque to
decelerate and stop the motor.
And then enter a free running state.
3
According to the deceleration time of Pn30A, the motor is
decelerated and stopped.
The state after stopping depends on the setting of Pn001 =
n.X.
4
According to the deceleration time of Pn30A, the motor will
decelerate and stop, and then enter the free running state.
n.X
Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
Pn00B
2
Function selection
application switch B
0000～1121
-
0000
Power
restart
Setup
-
n.X
Operator parameter display selection
Remarks
0
Only set parameters are displayed
1
Display all of the parameters
n.X
Stop Method in Case of Gr.2 Alarm
Remarks
0
Zero speed stop
1
DB stop or free running stop (stop method is the same as Pn001 =
n.X).
2
Set the stop method by Pn00A = n.X.
n.X
Power Input Selection for Servo Drive with Three-phase Input Specifications
Remarks
0
Use three-phase power input.
1
Three-phase input specifications are used for single-phase power
input.
n.X
Appointment parameters (do not change it)
Pn00D
2
Function selection
application switch D
0000～1001
-
0000
Power
restart
Setup
-
n. X
Appointment parameters (do not change it)
n. X
Appointment parameters (do not change it)
n.X
Appointment parameters (do not change it)
n.X
Overtravel Warning Check-out Selection
0
No over-travel warning is detected.
1
Check out over-travel warning.
Pn010
2
Axis Address:
（Modbus/CANopen/USB）
1～ 127
-
1
Power
restart
Setup
-
