Vibration testing and balancing device - Connections EasyBalancer EB 3500
3 - 4
3.5 Connections
Fig. 3-2: EasyBalancer EB 3500 connections, top
Fig. 3-3: EasyBalancer EB 3500 connections, bottom
1 Vibration sensor input
2 Photo and laser speed sensor
3 USB 2.0 mini-B interface for transferring measured data to a PC
4
Battery state of charge indicator lamp
Operation
Red: charging necessary / Green: sufficiently charged
Charging mode
Red: charging / Green: charged
5 Plug-in power supply input, 6V DC / 1.5 A
