Maintenance - Mains / charging operation EasyBalancer EB 3500
7 - 2
7.1.1 Charging batteries
Connect the charger (1).
Charging time: 4-5 h
Do not remove or reconnect the charger during
a measurement.
When removing the charger, always disconnect
the low-voltage plug from the device first.
Only then disconnect the charger from the mains.
7.1.2 Replacing the batteries
Connecting the charger when non-rechargeable
batteries are fitted could damage the device.
Loosen the Phillips screws (1).
Open the battery compartment.
Replace the batteries.
Make sure the correct type and polarity are used!
7.2 Mains / charging operation
7.2.1 Charger
6 V
1.5 A
Polarity: see sketch opposite
Risk of explosion
Use rechargeable batteries.
The charger must not be used if non-
rechargeable batteries are fitted.
4 rechargeable batteries Type AA, NiMH
1.2 V
min. 2700 mAh
