EasyBalancer EB 3500 Basic operation - Basic operation
4 - 5
4.2.3.3 Vibration sensor
Select sensitivity as per vibration sensor.
Standard value is 100 mV/g. Other values are
500 and 1000 mV/g.
4.2.3.4 Pre-selection
Go to “Method” and “File name” submenus.
Make selection, press .
Method Select between methods “Spread angle
with 2 weights” and “Spread angle with
3 weights”.
File name Enter and save file names for balancing
projects.
