Operation - Balancing EasyBalancer EB 3500
5 - 12
Zero run Position weights A, B and C at the specified
angles A = 0°, B = 120° and C = 240°.
The two weights are now in a neutral position.
Confirm with .
Starting a zero run
Switch on the machine and wait until
the final speed is reached.
Press the button.
The measurement starts.
The current speed appears on the display,
e.g. “n=1490” in rpm, the relative angular posi-
tion, e.g. “33°” and the vibration amplitude,
e.g. “0.93” in the selected physical unit: mm/s.
Wait until the measured value display is stable.
Stopping a zero run
Press the button (2).
The measurement ends.
Switch off the machine.
Risk of injury
When subsequently fixing the sliding
weights, make sure that they cannot
come loose from the balancing body
during rotation. Protective devices on
the machine or on the balancing body
must be closed. It is forbidden to
stand in the possible trajectory of the
test weight resulting from the rotation
of the balancing weight.
