Never use a fuse with a
different rating from that
specified. Serious damage to
the electrical system or a fire
may result.
124
Fuse
Replacement
Ifthefuseisblown,checkthe
cause, then replace the fuse with a
sparefuseofthesamerated
capacity. Unless the cause is found,
the fuse may blow again.
MAINTENANCE
BLOWN FUSE
15A FUSE
FUSE CASE LID
FUSE CASE LID
SPARE FUSE (30A)
30A FUSE
SPARE FUSE (15A)
Stop the engine.
Remove the engine cover.
Remove the fuse case lid and pull
the old fuse out of the clip with
your finger.
Push a new fuse into the clips.
If the fuse blows, running the engine
will not charge the battery. Before
replacing the fuse, check the current
ratings of the electrical accessories
and ensure that there are no
abnormalities.
2.
3.
4.
1.
