Honda BF75A - Oil Pressure Indicator Light;Buzzer; Overheat Warning Light;Buzzer

28
CONTROLS (R type)
Oil Pressure Indicator Light/
Buzzer
Overheat Warning Light/Buzzer
(R1 type)
(R2, R3 type)
(R1 type)
(R2, R3 type)
(GREEN)
(RED)
BUZZER
(GREEN)
BUZZER
BUZZER
OVERHEAT
WARNING LIGHT
(RED)
BUZZER
OIL PRESSURE
INDICATOR LIGHT
The engine speed slows down
gradually this time.
The oil pressure indicator light turns
off and the buzzer sounds when the
oil level is low and/or the engine
lubrication system is faulty.
The overheat warning light turns on
and the buzzer sounds when the
engine cooling circuit is faulty. The
engine speed slows down this time.
The buzzing sound stops below an
engine speed of 1,400 rpm.
