32
CONTROLS
(Common)
Emergency Stop Switch Emergency Stop Switch Lanyard/
Clip
(R1 type)
(R2, R3 type)
(H type)
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY STOP
SWITCH CLIP
EMERGENCY STOP SWITCH
EMERGENCY STOP SWITCH
EMERGENCY STOP SWITCH
The emergency stop switch lanyard is
provided to stop the engine
immediately in the event the operator
should fall overboard or away from
the controls.
The emergency stop switch clip must
be engaged with the emergency stop
switch or the engine will not start.
When the emergency stop switch clip
becomes disengaged with the
emergency stop switch the engine
will stop immediately.
