35
Anode Metal Cooling Water Check Hole Cooling Water Intake Port
Do not paint the anode metal. It
deteriorates the function of the
anode metal, which can lead to rust
and corrosion damage to the
outboard motor.
CONTROLS
(Common)
COOLING WATER CHECK HOLE
COOLING WATER INTAKE PORT
(EACH SIDE)
ANODE METAL
(EACH SIDE)
ANODE METAL (STERN BRACKET)
After starting the engine, check at the
cooling water check hole whether the
cooling water is circulating through
the engine.
The cooling water is checked here to
see whether it is circulating inside the
engine properly.
The anode metal is a sacrificed metal
which protects the outboard from
corrosion.
The engine cooling water is drawn
into the engine through this port.
05/10/26 09:49:35 3CZW0612_035
