37
CONTROLS
Fuel Line Connector Tachometer (equipped type)
(FUEL TANK SIDE)
FUEL LINE CONNECTOR
(OUTBOARD SIDE)
TACHOMETER
The fuel line connector is used to
connect the fuel line between the fuel
tank and the separate outboard motor.
The tachometer shows the engine
speed in revolutions per minute.
05/10/26 09:49:55 3CZW0612_037
