Honda BF75A - Remote Control Installation

＋
−
＋
44
Be sure to connect the ( ) side
battery cable first. When
disconnecting the cables,
disconnect the ( ) side first then
the ( ) side.
Unless the cables are properly
connected to the terminals, the
starter motor may fail to operate
normally.
If you connect the positive and
negative battery cables
incorrectly, or disconnect the
cables while the engine is
running, the charging system of
the outboard motor will break
down.
Remote Control Installation
Improperly installed steering
system, remote control box, and
remote control cable, or installing
those of the different types could
cause unpredictable accident.
Consult an authorized Honda
outboard motor dealer for proper
installation.
Do not place the fuel tank near
the battery.
INSTALLATION
SIDE-MOUNT
TYPE CONTROL
BOX
TOP-MOUNT
TYPE CONTROL
BOX (FOR DUAL
MOTOR TYPE)
PANEL-MOUNT TYPE
CONTROL BOX AND
SWITCH PANEL
TOP-MOUNT TYPE
CONTROL BOX (FOR
SINGLE MOTOR
TYPE)AND SWITCH
PANEL
The control box is available in three
types as shown.
Select the most suitable control box
for your outboard motor considering
the installation position,
operationability, etc. of the control
box.
See an authorized Honda outboard
motor dealer for further information.
