FRAME SERIAL NUMBER
ENGINE SERIAL NUMBER
STERN BRACKET
This Owner’s Manual is using the
following type names when it
describes the operations special to a
type.
Record the frame and engine serial
numbers for your reference. Refer to
the serial numbers when ordering
parts, and when making technical or
warranty inquiries.
Engine serial number:
The frame serial number is stamped
on the left stern bracket.
Frame serial number:
The engine serial number is stamped
on the cylinder block in front of the
motor.
Texts with no type indication are the
information and/or procedures
common to all types.
Check the type of your outboard
motor and read this Owner’s Manual
thoroughly before operation.
Top-mount type:
Panel-mount type:
Side-mount type:
The remote control type is classified
into the following three categories
according to the control box position.
Power trim/tilt type:
Gas assisted type:
Remote control type:
Tiller handle type: H type
R type
G type
T type
R1 type
R2 type
R3 type
