Install the outboard motor
securely. Loosely mounted
outboard motor can result in
accidental loss of the motor
and damage and injury to the
equipment and personnel.
40
INSTALLATION
LIFTING EYE
(optional)
Before installing the outboard motor
on the boat, hang the outboard motor
with the hoist or equivalent devise by
attaching the lifting eye to the
outboard.
Use the hoist which allowable load is
250 kg (551 lbs) or above.
05/10/26 09:50:20 3CZW0612_040
