Honeywell Accenta Series - Used Zones; Timed Zones

Accenta/Optima Engineer’s Manual
35
LCD Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as used,
• Press [PROG] to give a choice of programs or press
[up arrow] until P>Set Up Programs is displayed then press
[SET].
• Select program 1, 2 or 3.
• The first screen to appear is Program Edit Used Zones.
• Press [1] or [SET]. The first zone can now be set as used or
unused.
• To edit the other zones press [Number] or [up arrow] to go to
a particular zone.
• Press [RESET] three times to leave menu.
LED Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as used,
• Press [PROG] to give a choice of programs. LED’s 1, 2 and 3 are
flashing.
• Select program [1, 2 or 3]. If program 1 is selected, LED 1 is ON.
• Press [1] or [SET]. The first zone can now be set as used or
unused. If used, then LED is on
• To edit the other zones press [Number] to go to a particular zone.
Default settings are on.
• Press [RESET] three times to leave menu.
[PROG]
[1]
[1] or [SET]
[RESET]
12
3
4
5
6
7
8
12
3
4
5
6
7
8
