36
2 = Timed Zones
A zone programmed as Timed would be used to protect the main entry/exit door of the entry route.
LCD Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as timed,
• Press [PROG] to give a choice of programs or press
[up arrow] until P>Set Up Programs is displayed then press
[SET].
• Select program 1, 2 or 3.
• The first screen to appear is Program Edit Used Zones.
• Press [2] to enter into Timed Zones. The first zone can now be
set as timed or untimed.
• To edit the other zones press [Number] or [up arrow] to go to
a particular zone.
• Press [RESET] three times to leave menu.
[PROG]
[2]
1: Descriptor1: Descriptor
1: Descriptor1: Descriptor
1: Descriptor
Timed:Timed:
Timed:Timed:
Timed:
YESYES
YESYES
YES
P>Select ProgramP>Select Program
P>Select ProgramP>Select Program
P>Select Program
1 2 or 31 2 or 3
1 2 or 31 2 or 3
1 2 or 3
P>Program EditP>Program Edit
P>Program EditP>Program Edit
P>Program Edit
Used Zones Used Zones
Used Zones Used Zones
Used Zones
[Number]
[Number] or [up arrow]
2: Descriptor2: Descriptor
2: Descriptor2: Descriptor
2: Descriptor
Timed:Timed:
Timed:Timed:
Timed:
NONO
NONO
NO
[RESET]
P>Set UpP>Set Up
P>Set UpP>Set Up
P>Set Up
Programs Programs
Programs Programs
Programs
LED Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as timed,
• Press [PROG] to give a choice of programs. LED’s 1, 2 and 3 are
flashing.
• Select program [1, 2 or 3]. If program 1 is selected, LED 1 is ON.
• Press [2] to enter into Timed Zones. The first zone can now be
set as timed or untimed.
• To edit the other zones press [Number] to go to a particular zone.
Default settings are shown opposite.
• Press [RESET] three times to leave menu.
[PROG]
[1]
[2]
[RESET]
12
3
4
5
6
7
8
12
3
4
5
6
7
8
12
3
4
5
6
7
8
[Number]
Programs (cont’d)
12
3
4
5
6
7
8
12
3
4
5
6
7
8
To Next Page
