Model IFP-2100/ECS Installation Manual LS10143-001SK-E
7-3
7.3 List of SD SLC Devices
Table 7-3 list available SD SLC devices that can be used with the control panel. See the appropriate section
number in this manual or the device installation instructions (packaged with the device) for more information.
B201LP 6" mounting base I56-0595-00
B224BI 6" isolator base I56-0725-00
B224RB 6" relay base I56-3737-00
B200SR Sounder base I56-3392-00
B501 4" mounting base I56-0357-00
B200SR-LF
Low Frequency Sounder Base
I56-4152-00
B200S-LF
Low Frequency Sounder Base
I56-4151-00
Table 7-3 SD SLC Devices
Part Numbers MODEL NAME/DESCRIPTION
Install Sheet
PN
SD505-PHOTO Photoelectric smoke detector.
150955SD505-HEAT Absolute temperature heat detector. Trip point range from 135°F–150°F (0°C–37°C).
SD505-6AB 6" base
SD505-6IB 6" short circuit isolator base I56-3541-00
SD505-6RB 6" relay base I56-3542-00
SD505-6SB 6" sounder base I56-3540-00
SD505-DUCT Duct Smoke Detector. Duct Housing including the SD505- Analog Photoelectric
Smoke Sensor. Intake tubing for duct available in three lengths: SD505-T2 (2.5
foot); SD505-T5 (5 foot); SD505-T10 (10 foot)
1700-09882
SD505-DUCTR Duct Detector housing with relay base. Duct housing with relay base including
SD505- Analog Photoelectric Smoke detector pre-installed
1700-09882
SD500-PS/-PSDA Single or dual action addressable pull station I56-3632-00
SD500-AIM Addressable input module (switch input), standard size, DIP switch configurable
I56-3547-00
SD500-MIM Mini input monitor module (switch input), small size, DIP switch configurable.
SD500-ANM Addressable notification module I56-3544-00
SD500-ARM Addressable relay module DIP switch configurable. I56-3545-00
SD500-SDM Addressable smoke detector module. I56-3546-00
SD500-LIM Line isolator module. Fits in a double gang box. I56-3543-00
SD505-DTS-K Remote test switch & LED indicator for the SD505-DUCTR 1700-09882
Table 7-2 SK SLC Devices
Part Numbers Model Name/Description Install Sheet PN
