Model IFP-2100/ECS Installation Manual LS10143-001SK-E
12-13
12.2 SIA - IntelliKnight / IFP-2100/ECS Panels PI Modifier
Reporting:
Events are sent to the central station as a variable length string:
The event format is:
EEZZZZ
Where:
EE Event code (2 characters)
ZZZZ Event parameter (up to four digits – not zero filled)
1. The account number is sent using an account block that is separate from the event block
Zone-based AUX1 switch dis-
abled
pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
Zone-based AUX1 switch en-
abled
pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
Zone-based AUX1 switch trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Zone-based AUX1 switch trouble
restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Zone-based AUX2 switch alarm pi Exp. ID UA Point # UANNXXPPPP 1 140 Exp. ID Point #
Zone-based AUX2 switch alarm
restore
pi Exp. ID UH Point # UHNNXXPPPP 3 140 Exp. ID Point #
Zone-based AUX2 switch dis-
abled
pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
Zone-based AUX2 switch en-
abled
pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
Zone-based AUX2 switch trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Zone-based AUX2 switch trouble
restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
System-based Wireless Gateway
Trouble
pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
System-based Wireless Gateway
Trouble - restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Wireless Gateway Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Wireless Gateway Trouble re-
store
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Table 12-2: Reporting Formats Table
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA IFP-2100/ECS
Event Description Module
ID # (If
Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN -
panel ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
