Model IFP-2100/ECS Installation Manual LS10143-001SK-E
10-3
10.3.2 Using the Menus
10.4 Basic Operation
10.4.1 Setting Time and Date
1. Select 4 for Set Date & Time.
2. Make changes in the fields on the screen. Use right arrow to move through the fields. Use the up or down
arrow key to select options in the fields.
3. When the date and time are correct, press ENTER.
10.4.2 Disable / Enable a Point
1. Select 2 for Point Functions.
2. Select 1 for Disable/Enable Point.
10.4.2.1 Disable / Enable NACs by Template
1. Press 1 for Disable NACs by Template, or press 2 to Enable NACs by Template.
2. Use the up or down arrow key to move through the list of templates. Press ENTER to select the current tem-
plate.
10.4.2.2 Disable / Enable NACs by Group
1. Press 3 to Disable NACs by Group, or press 4 to Enable NACs by Group.
2. Use the up or down arrow key to move through the list of groups. Press ENTER to select the group high-
lighted.
10.4.2.3 Disable / Enable Zone Points
1. Press 5 to Disable Zone Points, press 6 to Enable Zone Points.
4- Set Time & Date Set time and date for the system.
5- Network Diagnostics Ping Panel, Data Network Status and Voice Network Status.
6- Network Programming Access Learn Network, Edit Network Names, Edit Panel ID, Computer Access, Access Codes,
Communicator Options, Voice Options, Sync Network Options.
7- Panel Programming Brings up a set of menus for programming the panel. These options are described in detail in
Section 9.
8- System Information Menus to view information about the panel such as model, ID, serial number, revision, send or
receive firmware updates and feature registration activation.
To move through the menus:
Use
the up or down arrow key to move through the options in a menu.
To select an option: Enter the number of the option, OR press ENTER if the option has the = symbol next
to it.
Exit Menu Left arrow
Main Menu Options Description
