Honeywell ECS Series

To Next Page

To Previous Page

Model IFP-2100/ECS Installation Manual LS10143-001SK-E

8-15

Zone

Edit Zone Select Zone

Edit Zone Name Section 9.3.1.1

Zone

Properties

Verification Type *1-Count Section 9.3.1.2

2-Count

Alarm Ver.

PAS

SNGL

ILOCK

DBL ILOCK

Heat Temp Set 135° to

150°F

SD devices

Section 9.3.1.2

135° to

190°F

IDP or SK

device Section

9.3.1.2

Smoke

Sensitivity

Low Section 9.3.1.2

Medium

High

Zone

Accessory

Opt

Single/Multi-

station Cadence

00-23 Section 9.3.1.3

CO Single/Multi

station Cadence

00-23

Local Zone Yes

View Zone Points Select Zone Section 9.3.2

Group Edit Group Select Group Group Name Section 9.4.1.1

Group

Properties

Voice Group Y or N Section 9.4.1.2

Switch 1-64

Template

Override

Y or N

Allow Sys

Override

Y or N

Dynamic Act/

Template

Override

Cadence

00-23

(See Appendix C)

View Group

Points

Select Group Section 9.4.2

Edit OPG

Template

Select template Modify name and which OPGs are in template Section 9.4.3

Menu Options/Defaults Comments

Main Page

Default Chapter2
- Fire Alarm & Emergency Communication System Limitations2
- Installation Precautions3
- Documentation Feedback4
- Table of Contents5
Section 114
- Overview of Basic System14
  - Hardware Features14
Introduction14
- Network System Hardware Features15
- Software Features15
- IFP-2100ECS Features15
- Compatible Products16
  - Terms Used in this Manual16
Section 219
Agency Listings, Approvals, and Requirements19
- Federal Communications Commission (FCC)19
- Underwriters Laboratories (UL)20
Section 324
Before You Begin Installation24
- Inventory24
- Environmental Specifications24
- Software Downloads24
- Electrical Specifications25
- Terminal Descriptions and Electrical Specifications26
- Wiring Specifications27
  - Wire Routing Example for 682027
  - Wire Routing Example for IFP-2100ECS28
- Board Assembly Diagram29
- Model IFP-2100 Assembly29
- Calculating Current Draw and Standby Battery30
Section 443
Control Panel Installation43
- Mounting the Control Panel Cabinet43
  - Preventing Water Damage43
- AC Power Connection44
  - Removing the IFP-2100/ECS Assembly from the Housing44
  - Ethernet Connection44
- Battery Power45
  - Battery Accessory Cabinets45
- SBUS Wiring48
  - Calculating Wiring Distance for SBUS Modules48
  - Wiring Configurations51
    - SBUS Class a Wiring51
    - SBUS Class B Wiring51
- RA-2000 Remote Annunciator Installation52
- RA-1000 Remote Annunciator Installation56
- 5815XL Installation64
  - 5815XL Connection to the Panel64
  - 5815XL Board64
- 6815 Installation65
- 5824 Serial/Parallel Interface Module Installation67
  - Selecting 5824 Options67
    - 5824 Connection to the Panel67
    - Printer and Output Port Options67
- 5880 LED I/O Module69
- 5865-3 / 5865-4 LED Annunciator Installation72
  - FACP Connection72
  - 5865 Mounting73
- Configuring SBUS Modules74
  - Assigning SBUS Module Ids74
  - SBUS Bandwidth Considerations74
- Telephone Connection75
  - Conventional Notification Appliance75
    - Class B Notification Wiring75
- Flexputs ™ I/O Circuits75
- On-Board Relays (Conventional)82
- Remote Station Applications83
Section 588
- Network Wiring88
  - Wiring Options to Connect Networked Panels88
  - Networked Sites88
- Network System Hardware Features88
- Model RFP-210088
  - External SK-NIC Wiring Option89
  - Internal SK-NIC Wiring Option89
- SK-NIC Wiring Options90
  - Fiber Loop Modules90
    - Accessory Mounting Kits91
  - SK-NIC Installation91
- Setting the Network ID for each Panel97
- Network ID Settings97
Section 698
Network Management98
- Network Diagnostics98
  - Ping Panel98
- Network Programming98
- Voice Options103
- Sync Network Options105
- Network Management Quick Reference106
Section 7110
- List of SK SLC Devices110
IDP, SK, SD and SWIFT™ SLC Device Installation110
- List of SD SLC Devices111
- List of SWIFT Wireless SLC Devices112
- Maximum Number of SLC Devices112
- Wiring Requirements for SLC Devices112
- Addressing IDP or SK SLC Devices115
- Class a SLC Configuration115
- Wiring SD Detectors116
- Addressing SD Devices116
- Wiring the WIDP-WGI or SK-WGI119
  - Power Connections for the Gateway119
Section 8120
Programming Overview120
- Jumpstart Autoprogramming120
- Mapping Overview123
- Programming Using the HFSS Honeywell Fire Software Suite131
- Programming Using an Annunciator131
  - Entering / Exiting Panel Programming131
- Programming Menu Quick Reference133
Section 9144
- UL 864 / UL 2572 Programming Requirements144
- System Options164
- Restore Defaults173
- Jumpstart® Autoprogramming173
- Voice Options173
  - VCM Maintenance174
  - Voice Settings174
    - Enable Dual Channel System174
Section 10175
System Operation175
- Default User and Installer Codes175
- Annunciator Description175
- Menu System176
  - Main Menu Overview176
    - Single Key Acknowledge176
- Basic Operation177
- Event Priority183
- Operation Mode Behavior185
- Smoke Alarm Verification192
- Function Keys192
Section 11194
Emergency Communication System Operation194
- Overview194
- LOC Functionality194
- ECS Super User199
- ECS Point Functionality200
- Amplifier Programming200
- LOC Programming201
  - Editing an Amplifier201
  - Adding an LOC201
- Using the Microphone202
- Recording Custom Messages204
- Network Paging209
  - Priority209
  - Configuration210
Section 12211
Reporting211
- Receivers Compatible with the Control Panel211
- Reporting Formats Table211
- SIA - Intelliknight / IFP-2100/ECS Panels PI Modifier Reporting223
- SIA - IFP-2100/ECS Panel Communicator224
Section 13226
Testing and Troubleshooting226
- Common Problems226
- Periodic Testing and Maintenance227
- Before Testing227
- Event History228
- Built-In Troubleshooting and Testing Tools228
Section 14231
Installation Records231
- Detector and Module Point Record231
- Conventional Output Point Record235
