Addressable SLC Detectors
SK-PHOTO
Standby/Alarm: .30 mA
1
mA mA
SK-PHOTO-T mA mA
SK-HEAT mA mA
SK-HEAT-HT mA mA
SK-ACCLIMATE mA mA
SK-HEAT-ROR mA mA
SK-DUCT
5
(includes PhotoR)
mA mA
SK-BEAM (without integral test)
SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-BEAM-T
4
(with integral test)
SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-FIRE-CO
SLC Standby: .30mA mA
Alarm: 7.2mA mA
Addressable SLC Module
SK-MONITOR
Standby/Alarm: .375 mA
mA mA
SK-MINIMON mA mA
SK-PULL-SA mA mA
SK-PULL-DA mA mA
SK-MONITOR-2 Standby/Alarm: .75 mA mA mA
SK-MON-10 Standby/Alarm: 3.5 mA mA mA
SK-CONTROL
SLC Standby: .375 mA mA
Alarm: .375 mA mA
Aux Pwr Standby: 1.7 mA mA
Alarm: 7 mA mA
SK-CONTROL-6
SLC Standby: 2.25 mA mA
Alarm: 2.25 mA
Aux Pwr Standby: 8 mA mA
Alarm: 20 mA mA
SK-RELAY Standby/Alarm: .255 mA mA mA
SK-RELAY-6 Standby/Alarm: 1.45 mA mA mA
SK-RELAYMON-2
Standby: 1.3 mA mA
Alarm: 24 mA mA
SK-ZONE
Aux Pwr Standby 12 mA mA
Alarm 90 mA mA
SLC Standby/
Alarm .27 mA
mA mA
SK-ZONE-6
Aux Pwr Standby 50 mA mA
Alarm 270 mA mA
SLC Standby/Alarm 2 mA mA mA
Table 3-3 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm
Current
