10 Technical Specifications
The main technical data are noted on various type plates and labels on the device. They
are also listed below and can be found in total on the data sheet.
Installation
Place of use
Installation close to the sampling point up to Ex Zone 1
If installed outdoors, the device may need a sun shade or have to be placed
in an air-conditioned housing
Installation
Wall mounting using a supplied bracket or
installation on a bench or platform
Mechanical
Dimensions
Base Ø 37 mm x height 37 cm (Ø 14" x height 14")
Installation Clearance: Ø 55 cm x Height 70 cm (Ø 20” x Height 28”)
Weight:
28 kg
Approvals
ATEX (EN 60079-0: 2012/EN 60079-1: 2014)
IECEx (IEC 60079-0: 2011 Sixth edition/IEC 60079-1:2014 seventh edit.)
INMETRO:
NEC Class I/Div. 1, Groups B, C & D
NEC Class I/Zone 1 AEx db IIC T6
Mechanical
strength
Vibration and shock test to IEC 60068-2-31 and -64
Enclosure
IP 66
Electrical
Electrical Safety
Designed to be installed in hazardous areas.
Power supply
(single supply)
Maximum
current/rating
24 VDC, 50W nominal non-heated
and 120 W nominal heated version (ambient < 0 °C)
Created for example with Quint-PS-100-240AC / Quint-PS-
24DC/24DC/10 / Siemens SITOP / Siemens Logo or equivalent power
supply units with safe electrical isolation
Battery back-up
Button battery, Panasonic Type BR 2032 3V
EMC strength to EN 61000-6-2 and EN 61000-6-4
