73022344 o
5 Housing interior with major internal components
Only the hood must be removed for inspections, maintenance work and the electrical
installation.
CAUTION
DO NOT OPEN THE DEVICE IF.
•
IT IS IN A POTENTIALLY EXPLOSIVE ATMOSPHERE
•
THE CONDITIONS DESCRIBED IN ISO/IEC 61010-1 ARE NOT
COMPLIED WITH
•
YOU DO NOT HAVE THE PERMISSION OF THE MANUFACTURER
AND OF THE STATION OPERATOR TO DO SO
Turn the security screws as far as possible downwards to allow the hood to be removed.
As soon as the hood has been unscrewed and removed, almost all the internal
components are directly accessible:
CAUTION
When the device is open, there is a risk of damaging the internal
components and thus generating safety problems and malfunctions.
You should therefore complete the work with the appropriate care and
always obey the explosion protection regulations.
The open housing provides a view of the layout of the main components and internal
parts. The skid is designed to secure the various components. It enables most
components to be removed by unscrewing just a few screws.
Due to the long application time of the device and the different conditions of use,
individual components are used in different variants. The following figure shows the
exploded view of the different internal components of the Master Unit of the EnCal3000,
the individual parts and variations are explained in detail with the functionalities of each
component in the following paragraphs.
