3.2 Most important features and functions
•
Compact EX-d design allows for the harshest conditions imaginable in natural
gas applications
•
installation clearance Ø 55 cm x 70 cm height, weight <30 kg
•
Complete stand-alone operation
•
mount the device on a platform, a pole or to the wall
•
Capillary and micro packed columns in combination with MEMS analytical
components
•
Fast analysis (C6+ in less than 3 minutes)
•
High analytical performance :
•
Uncertainty < 0.1 % for a wide range of gases
•
Repeatability < 0.005 %
•
Up to 5 sample streams sequential without external stream selection
•
All gas tubing (sample lines, cal. gas, vent lines, helium in and out) and all
electrical connections can be directly connected to the unit.
•
Integrated sample system
•
Internal data storage for the last 35 days of all data
•
Suitable for extreme environmental conditions
•
Two analytical modules (which do each a part of the total analysis, in parallel)
•
Processor board
•
Internal sample system (stream selection and pressure regulation)
•
All electrical field connections (Ethernet, ModBus, analogue IN, digital I/O,
solenoid drivers), fuses, switches and jumpers
•
Explosion proof certified for ATEX / IECEx / NEC
•
IP 66 ingress protection against dust and precipitation (suitable for offshore
applications)
•
Standard temperature range: 0 to +60 ° C (32 to 140 ° F), optional extension for
devices with ATEX/IECEx-Approval. 0 to 55°C (32 to 130°F) for devices with
FM-Approval with internal heating to -20 ° C (-4 ° F), with internal heating and
external insulation to -40 ° C (-40 ° F)
•
EMC certification according to EN 61000-6 - 2/4 (Industrial devices)
•
Vibration and shock test according to OIML D11 11- 1/2
•
Coating according to Shell specifications DEP 40.4800.30 for off-shore
applications
•
For check or maintenance procedures of most parts, only the cap has to be
removed.
The following paragraphs give a general description of the main parts of the unit.
