POSSIBLE HARDWARE OP
TIONS AND
TYPE PLATES
EnCal 3000
Hardware
Manual
73022344 o
108
Gas Cylinders
Carrier gas
Helium / Argon
Quality 5.0
or better
50 l gas cylinder(not always included in Honeywell package)
Option: 2 cylinders with automatic changeover system
Supply pressure 5.5 barg
Flow ± 4 ml/min per column (max. 8 ml/min with 2 columns)
Ensure that only suitable standard-compliant types are used if you do not
source them from Honeywell. Cylinder pressure greater than 1.0 MPa(g)
required. At a pressure below 2 MPa, keep a replacement cylinder available.
Other accessories required: pressure regulators and connection lines.
Calibration gas
Quality 2.0 or
higher
10 l gas cylinder (not always included in Honeywell package)
Composition preferably close to pipe line composition
(with a maximal uncertainty of 1% relative deviation for each component)
Supply pressure 1 to 4 barg nominal Pressure peak protection up to 4 barg
Flow ± 30 ml/min
Ensure that only suitable standard-compliant types are used if you do not
source them from Honeywell. Cylinder pressure greater than 1.0 MPa(g)
required. At a pressure below 2 MPa, keep a replacement cylinder available.
Other accessories required: pressure regulators and connection lines
11 Possible hardware options and type plates
The EnCal 3000 can be delivered with several options. These options are described in
the following segments of this appendix.
Option
Meaning
Explanation
HT Heaters
installed
Frost protection has been added to keep the internals in the
housing above 0 degrees Celsius
SC Single
Channel
This a single channel analyser
QS Quad Slave This housing is the slave (2nd dome) housing of an EnCal
3000 Quad. It has no CPU board inside.
H2 Hydrogen This analyser is configured to work with Hydrogen as carrier
gas. As such it needs venting of the carrier to safe area.
